TECHNICAL SPECIFICATIONS
Handheld Explosive Detector


Type Handheld
Technology Amplified Fluorescence Polymer Technology
Radiation Type Non-Radioactive
Detection modes Particle & Vapour mode
Carrier gas required for Detection No
Explosives types Detected Detects almost all Commercial, Military & country made explosives existing to date
Detection time <30 Secs
Warm-up Time <30 Secs
Alarm Audio,Visual, Haptic (Vibration)
False alarmrate <1 percent
Software Proprietary embedded software running on microcontroller
Sensitivity for Explosives Nanogram level,Picogram level,ppb level, ppm level
Time between Two Successive Tests(MINUTES) <1
Calibration Automatic
Type of Display COLOR LCD, Touch screen
Supporting software for connecting to PC & Printer Yes
Memory 4GB. Option upto 60GB
Date /time Stamp in Entries Yes
Communication Micro USB
Power Source Rechargeable Battery
Battery Chemistry, if Rechargeable Battery Li-lon
Number of Batteries required for operation 1
Number of spare Batteries supplied 2
One charge Battery Life 4-6 Hours
Suitable Adapter supplied Yes
Weight 620 Grams
Dimension 230mmX 100mm X 65mm
Other features, if any No extra accessories / attachments
Minimum Operating temperature -10 degree Celsius
Maximum Operating temperature 55 degree Celsius
Operating humidity at 40 deg C 95 percent
Warranty 12 months from the date of invoice
Availability of Test Reports from Central Govt/ NABL/ILAC acredited lab to prove confirmity to the Specifications Yes
If Yes, Test Report to be furnished to the Buyer on demand Yes
Test Report Number and Date NTH(NR)EL(A)2019/00303
Name and Address of the Lab National Test House
